TRIPLE WALLED HIGH PRESSURE WING NUT AUTOCLAVE. (LIC- 125)

INCLUDING

  • Water level indicator.
  • Stainless steel basket.
  •  Vacuum breaker
SIZE(INCHES) 10 *18 12 *20 14 *22 16 *24 18 *24 22 *30
SIZE (MM) 250*450 300*500 350*550 400*600 450*600 550*750
CAPACITY 22 liters 40liters 50liters 78liters 98liters 180liters
LOAD 1.5kw 2.0kw 3.0kw 4.0kw 4.0kw 5.0kw
ALL S.S 304 P.O.R P.O.R P.O.R P.O.R P.O.R P.O.R

CONSTRUCTION

FULLY S.S WING NUT MODEL
Inner chamber SS 304
Outer chamber SS 304
Lid SS 304
Gasket Silicon joint less
Ring SS 304
Leg stand MS 202
Heater SS 316
Socket & Pipe Line SS 304

SEMI AUTOMATIC

Automatic low water cut off system P.O.R
Automatic Pressure control switch P.O.R
PID temperature indicator cum controller P.O.R
FULLY AUTOMATIC PID PURGING SYSTEM
Automatic low water cut off system P.O.R
Automatic Pressure control switch P.O.R
Control: ON/OFF / T.P.

Input: PT-100 Pressure Sensor for chamber.

Purging Range: User Settable.

Sterilization Time: User Settable.

Post Sterilization-Drying Time: User Settable.

Boiler Control: User Settable.

Buzzer: High / Low Alarm/Process End.

Pressure Display.

Sterilization cycle process inbuilt

P.O.R
