Fortins Barometer

Technical Specification: –

A glass tube of 6mm bore is enclosed in an enamelled and lacquered brass case, mounted on a polished wooden board with plates for fixing on wall. Open plate reflectors, ring and screws for vertical adjustments. A dual scale graduated in 25 to 32 inches and 640 to 810mm is read by verniers moving by rack and pinion, reading to 0.002 inch and 0.1mm are enclosed in a glass cylinder. A glass cistern at the lower end of barometer is provided with an ivory point to adjust the level of mercury. A thermometer -10 to 50C is provided on the wooden board. Supplied without mercury and glass case.
